Measurements

14 results

AVID Acutus turntable with the Nexus tonearm and Reference Ruby cartridge.

AVID Reference Ruby

AVID Acutus · Nexus

Playback speed
33.20 RPM
Speed error
−0.39%
DIN-shaped W&F RMS
0.059%
Separation
37.6 dB

A standout 37.6 dB of average separation at 1 kHz. In Groove Scope Studio, the 90 and 100 µm tracking steps passed cleanly. The 80 µm step failed and showed an isolated spike.

Measurement details
Channel balance
+0.43 dB (L−R)
Crosstalk difference
4.27 dB between directions
Tracking test
Separate Groove Scope Studio capture at 17:26. The failed 80 µm step had a much shorter usable interval than the passing steps.
Record status
Published
Takumi TT Level 2.1 DC turntable.

Takumi Aka MC

Takumi TT Level 2.1 DC · ART preamp

Playback speed
33.33 RPM
Speed error
0.00%
DIN-shaped W&F RMS
0.030%
Separation
27.0 dB

The average speed matched the target at the report’s displayed precision. Excellent vibration rejection stood out during the session, and trackability was moderate.

Measurement details
Channel balance
+0.07 dB (L−R)
Post-adjustment crosstalk
−27.6 dB L→R and −26.4 dB R→L after azimuth adjustment, with some misalignment still present. An imperfection in this cartridge sample could also have contributed. The low capture level may have limited the estimate.
Record status
Published
Close-up of the orange Ortofon 2M Bronze and SME III tonearm on the Thorens TD 160 Super, cosmetically retouched.

Ortofon 2M Bronze

Thorens TD 160 Super · SME III · ART preamp

Playback speed
33.30 RPM
Speed error
−0.11%
DIN-shaped W&F RMS
0.028%
Separation
32.2 dB

An initial 5.86 dB imbalance prompted an azimuth adjustment. The measurer also reported a marked improvement after adjusting anti-skate.

Measurement details
Final channel balance
+0.44 dB (L−R)
Directional crosstalk difference
1.72 dB
Record status
Published
SME Model 12 MkII setup photographed at Entertainment Machine in Rome.

Charisma Audio MC-1 Alpha

SME Model 12 MkII · SME 309

Playback speed
33.32 RPM
Speed error
−0.04%
DIN-shaped W&F
0.038%
Separation
22.0 dB

Close to nominal speed, with a 5.57 dB difference between crosstalk directions. Measured at Entertainment Machine, DSR’s first specialised Groove Scope Studio testing point and first certified reseller in Rome.

Measurement details
Channel balance
+1.28 dB (L−R)
Follow-up
Check routing and gain, then repeat the 1 kHz capture on this setup before making mechanical adjustments.
Record status
Published
Rega Carbon cartridge on the Rega Planar 1 at the AudioReview laboratory, with ImageGen retouching.

Rega Carbon

Rega P1 · AudioReview laboratory · ART preamp

Playback speed
33.22 RPM
Speed error
−0.35%
DIN-shaped W&F
0.036%
Separation
31.8 dB

The cartridge looked square. An azimuth adjustment cut the crosstalk imbalance from 10.27 to 1.16 dB, and a separate tracking test went from 60 to 80 µm.

Measurement details
Azimuth
Adjusted using Groove Scope
Tracking test
60 µm at 2.0 g and 80 µm at 2.5 g using Groove Scope Studio
Record status
Published
New Horizon turntable with an Ortofon 2M Bronze, photographed during the measurement session.

Ortofon 2M Bronze

New Horizon · ART preamp

Playback speed
33.41 RPM
Speed error
+0.23%
DIN-shaped W&F
0.053%
Separation
23.6 dB

The speed fingerprints show a recurring slowdown and changes in the faster portions over eight rotations.

Measurement details
Azimuth
No adjustment during the session
Tracking test
70 µm unsuccessful, as reported by the measurer
Record status
Published
Photograph of the Thorens TD 160 Super and SME III tonearm from the measurement session.

Audio-Technica VM95SH

Thorens TD 160 Super · SME III · ART preamp

Playback speed
33.29 RPM
Speed error
−0.12%
DIN-shaped W&F
0.030%
Separation
17.7 dB

Groove Scope made azimuth easy to improve from a much worse starting position. A bent cantilever limits the cartridge findings, and a repeating speed pattern points to follow-up work on the Thorens.

Measurement details
Stylus condition
Bent cantilever
Channel balance
+2.90 dB
Record status
Published
Shure V15 V with JICO MR stylus; supplied photograph cosmetically retouched with teal and amber backlighting.

Shure V15 V

Micro Seiki DQX500 · MA707 · Audio Research SP20 · Audient EVO4

Playback speed
33.33 RPM
Speed error
−0.02%
DIN-shaped W&F
0.025%
Separation
27.3 dB

A new JICO Custom Shop MR stylus and careful azimuth adjustment bring fresh promise to an original Shure V15 V, with closely matched channel output.

Measurement details
Stylus
New JICO Custom Shop MR
Audio interface
Audient EVO4
Channel balance
−0.01 dB
THD, left / right
0.65% / 0.49%
Record status
Published

Clear, revealing sound and a quiet background are the measurer’s listening impressions. Repeat the right-channel third-harmonic check before further setup changes.

BENZ SPJ on a VYGER Atlantis; original CHARIO Academy event photograph.

BENZ SPJ

VYGER Atlantis · VYGER INERTIAL · ART USB Phono Plus

Playback speed
33.33 RPM
Speed error
−0.01%
DIN-shaped W&F
0.032%
Separation
27.4 dB

A reported 100 µm tracking-ladder pass with no setup adjustments: the measurer credits the new VYGER INERTIAL tonearm as a major contributor.

Measurement details
Audio interface
ART USB Phono Plus
Channel balance
+0.49 dB
THD, left / right
0.96% / 1.06%
Record status
Published

Quick show-room capture. The 100 µm ladder pass is a separate measurer-reported observation. With thanks to Pino Viola.

Ortofon 2M Bronze on a Rega P3; cosmetically retouched supplied photograph.

Ortofon 2M Bronze

Rega P3 · Audio Research SP20 · EVO4

Playback speed
33.34 RPM
Speed error
+0.01%
DIN-shaped W&F
0.027%
Separation
32.8 dB

Strong 32.8 dB average separation and closely matched channels: a compelling 2M Bronze result in this Rega P3 system.

Measurement details
Audio interface
EVO4
Channel balance
+0.53 dB
THD, left / right
0.98% / 1.13%
Record status
Published

Repeat the right-channel third-harmonic check before changing cartridge setup, as the report advises.

Technics SL-1410 MK2 turntable with Empire 7000/III cartridge; background removed and lighting cosmetically enhanced.

Empire 7000/III

Technics SL-1410 MK2 · ART USB Phono Plus

Playback speed
33.33 RPM
Speed error
−0.01%
DIN-shaped W&F
0.040%
Separation
23.8 dB

Near-nominal average speed and steady harmonics; the two measured crosstalk directions differ by about 2 dB.

Measurement details
Input interface
ART USB Phono Plus (USB Audio CODEC)
Channel balance
−0.26 dB
THD, left / right
2.26% / 1.85%
Record status
Published

Harmonics were steady during recording. A repeat capture can test the persistence of the channel differences.

Illustrative DQX-500 photograph from the earlier measurement session.

Goldring 2100

Micro Seiki DQX-500 · Audio Research SP20 · EVO4

Playback speed
33.33 RPM
Speed error
−0.01%
DIN-shaped W&F
0.032%
Separation
20.1 dB

Near-nominal average speed; the report advises repeating the capture because the right-channel third harmonic changed most.

Measurement details
Audio interface
EVO4 (measurer supplied)
Channel balance
−0.54 dB
THD, left / right
1.72% / 2.15%
Record status
Published

The measurer confirmed the chain separately; the reused hero is illustrative and the PDF input field is blank.

Editorial view of the photographed Micro Seiki RX-5000, SME V and Transfiguration Orpheus.

Transfiguration Orpheus

Micro Seiki RX-5000 · SME V · EVO4

Playback speed
33.51 RPM
Speed error
+0.52%
DIN-shaped W&F
0.031%
Separation
19.5 dB

The mean speed measured +0.52% while DIN-shaped wow and flutter was 0.031%; harmonic levels were steady in this capture.

Measurement details
Audio interface
EVO4 (measurer supplied)
Channel balance
−0.35 dB
THD, left / right
0.87% / 1.18%
Record status
Published

Harmonic levels were steady during this recording. A repeat capture can test whether the mean speed and channel patterns persist.

Audio-Technica AT-OC9XML cartridge on a Rega RB330 tonearm playing a record.

Audio-Technica AT-OC9XML

Rega P3 · RB330 · Audio Research SP20

Playback speed
33.34 RPM
Speed error
+0.02%
DIN-shaped W&F
0.030%
Separation
31.8 dB

Strong 1 kHz separation and near-nominal mean speed; repeat before using the changing left-channel third harmonic to guide setup.

Measurement details
Tonearm
Rega RB330
Preamplifier
Audio Research SP20
Input interface
EVO4 (report label)
Tracking force
2 g
Turntable support
Wall shelf
Channel balance
−0.24 dB
THD, left / right
0.29% / 0.37%
Record status
Published

Overhang was checked and confirmed correctly aligned. The left-channel third harmonic varied most during recording; a repeat capture can establish whether the pattern returns.

The setup gives the numbers meaning.

Cartridge, alignment, tonearm, turntable, test record, phono stage and capture path all contribute to the result. These measurements describe a documented playback chain and session. Repeat captures add context while preserving the original evidence.
